Home Miscellaneous Tools & Sundries Testing Equipment Pro Digital Multimeter. AC/DC Voltage, Current, resistance & capacitance.
Picture of Pro Digital Multimeter. AC/DC Voltage, Current, resistance & capacitance.
Picture of Pro Digital Multimeter. AC/DC Voltage, Current, resistance & capacitance.

Pro Digital Multimeter. AC/DC Voltage, Current, resistance & capacitance.

STOCK CODE: HT-DIGMULTPRO
The digital multi-meter (DMM) is a handheld tool which can measure capacitance, voltage, electrical current and resistance with diode and continuity check. There is also a “hold” function available in the compact design making it very user-friendly. The multi-meter is also CAT III rated for 600V. With built-in non-contact AC voltage detection, this battery-powered device is great for continuity and portability. A robust, double-moulded, plastic housing provides ultimate protection from harsh environments. Included with the multi-meter itself are integral test leads, 29V battery, type K temperature probe and a user manual.
Multimeter Type  Handheld
Functions Measured  AC Current, AC Voltage, DC Current, DC Voltage, Resistance, Temperature
True RMS  NO
Display Type  LCD
Operating Temperature (Min to Max)  0 °C to 50 °C (32 °F to 122 °F) at < 70 % relative humidity
Storage Temperature (Min to Max) -20 °C to 60 °C (-4 °F to 140 °F) at < 80 % relativehumidity
Diode Test  Yes
Continuity Test  Yes
Auto power off  Yes， / Approx. 15 minutes after last operation
Insulation  Class2, Double insulation.

Type  Absolute Maximum Measurement
DC Current  10A dc
AC Current  10A ac
Resistance  20MΩ
DC Voltage  600V dc
AC Voltage  600V ac
Temperature  +1000 °C, +1832 °F
Frequency  60Hz

Battery Type  IEC 6F22, NEDA 1604, 9V
Safety Category Voltage  600 V, 1000 V
Product Description
Dimensions  70 x 48 x 150mm
Width  48mm
Length  70mm
Height  150mm
Weight  255g
